Product Overview
A DIN 42539 low voltage transformer bushing rated 3 kV at 250 A with a 120 mm creepage distance. The assembly is fully specified: porcelain shell, NBR gaskets, copper threaded rod, blued steel spin grip nut, zinc-plated brass connector, and stainless steel lock washer and nut. The DIN 42539 family runs from 250 A up to 6500 A with creepage rising from 120 mm to 140 mm.
- DIN 42539
Why Buyers Choose This Part
- Complete assembly with gaskets, connector and hardware specified by material
- NBR gaskets and stainless steel fasteners for a durable oil seal
- Part of a DIN 42539 family spanning 250 A to 6500 A
- Special lengths and screw sizes made to customer specification
Where It Is Used
- 3 kV low voltage transformer terminals on DIN patterns
- Transformer assembly lines standardising on DIN 42539
- Replacement where the original hardware set is no longer available
- Projects needing several current ratings from one DIN family
Who It Suits
- Transformer manufacturers building to DIN 42539
- Repair shops replacing complete bushing assemblies
- Distributors stocking the DIN 42539 range
What Goes Wrong Without The Right Part
- Bushings supplied without the gaskets and hardware needed to fit them
- Oil leaks at the flange from the wrong gasket material
- Galvanic problems from mismatched connector and fastener metals
- Mixed current ratings across a transformer range needing one supplier
How It Is Built
- DIN 42539 at 3 kV and 250 A
- 120 mm creepage distance
- Porcelain shell
- NBR gaskets
- Copper threaded rod
- Blued steel spin grip nut
- Zinc-plated brass connector
- Stainless steel lock washer and nut
Published Figures For This Product
Every value below comes from the manufacturer data for this item. Figures not listed are confirmed against the drawing before an order is placed.
| Creepage Distance | 120 mm |
|---|
Materials
- Electrical porcelain
- NBR gasket
- Copper threaded rod
- Zinc-plated brass connector
- Stainless steel washer and nut
Process
- Forming
- Glazing
- Firing
- Rod machining
- Gasket and hardware assembly
- Routine test
Testing
- Creepage verified against the 120 mm figure
- Gasket seating and seal check
- Thread and connector fit inspection
Certification
- Manufactured to DIN 42539
- ISO 9001 quality management system
Customisation Options
- Special lengths made to customer specification
- Different screw sizes on the threaded rod
- Other DIN 42539 current ratings up to 6500 A
How It Compares
| DIN 42539 3kV 1000A | Creepage steps up from 120 mm to 125 mm and the conductor path is sized for four times the current. Match the bushing to the transformer LV output. |
|---|---|
| DIN 42530 1 kV series | DIN 42530 covers the 1 kV class with creepage from 50 mm. DIN 42539 is the 3 kV family, so the two are not interchangeable. |
Before You Order And After It Arrives
- Order the complete assembly so gaskets and hardware match
- Confirm the threaded rod screw size against your busbar connection
- Replace NBR gaskets whenever the bushing is removed
- Tighten the lock nut against the washer, not against the porcelain
DIN 42539 3kV 250A Transformer Bushing DT3KV-250A Questions
