ShF-10G Ceramic Pin Insulator Standard Listing

• Home
• Products
• Pin Type Insulators
• ShF-10G Ceramic Pin Insulator Standard Listing

Product Overview

The catalogue listing of the ShF-10G ceramic pin insulator, the 10 kV member of the ShF pin family used across CIS distribution networks. It carries line conductors on pin spindles and is ordered against the ShF-10G designation. Full drawing values for this listing are confirmed on request before the order is placed.

Why Buyers Choose This Part

• Held as a distinct catalogue listing for buyers ordering by designation
• Same ShF-10G pattern used across CIS 10 kV distribution networks
• Glazed porcelain body suited to long outdoor exposure
• Supplied alongside the rest of the ShF range from one factory

Where It Is Used

• 10 kV distribution line construction and repair
• Bulk stock orders against the ShF-10G designation
• Networks standardising pin hardware on the ShF family
• Line refurbishment matching existing installed insulators

Who It Suits

• Line construction crews at 10 kV
• Utility stores holding ShF pin insulator spares
• Distributors quoting from CIS catalogues

What Goes Wrong Without The Right Part

• Orders that have to be placed against a specific catalogue designation
• Pin insulator supply split across several vendors
• Replacement units that do not match the installed spindle thread
• Small repeat quantities local suppliers will not run

How It Is Built

• ShF-10G designation
• 10 kV distribution class
• Glazed electrical porcelain body
• Pin spindle mounting with conductor tie groove

Published Figures For This Product

Every value below comes from the manufacturer data for this item. Figures not listed are confirmed against the drawing before an order is placed.

Distribution Class	10 kV

Materials

• Electrical porcelain body
• Metal pin fitting

Process

• Forming
• Glazing
• Firing
• Fitting assembly
• Routine test

Testing

• Glaze and body inspection on every unit
• Dimensional check against the ShF-10G drawing
• Routine electrical test before despatch

Certification

• ISO 9001 quality management system

Customisation Options

• Pin thread matched to your existing spindles
• Produced to drawing or sample
• Own-brand marking under OEM arrangement

How It Compares

The detailed ShF-10G listing	The same insulator is also published with full test values: 256 mm minimum creepage, 12.5 kN bending load, 100 kV impulse withstand and 1.8 kg weight.
ShF-20G1	The 20G1 is the 20 kV part with longer creepage and a stringing sleeve. Match the class to the line voltage.

Before You Order And After It Arrives

• Order against the designation printed on your parts list
• Confirm the spindle thread before committing to quantity
• Tie the conductor into the groove properly
• Replace any unit with a chipped groove rather than reusing it
