GRADE 80 EYEBOLT/Alloy Steel Eye Bolt
GRADE 80 EYEBOLT/Alloy Steel Eye Bolt is supplied by Kailipu as part of the Grade 80 Links family from Qingdao, and is quoted against the size, capacity and finish your requirement calls for.
15 Grade 80 master links and ring connectors in A342 A343 A345 A346 patterns from 1 in to 4 in. Galvanised or plain finish. EN 10204 3.1 MTC on reques
Specifications
| Material | Grade 80 alloy steel |
|---|---|
| Surface finish | Red painted |
| Standards | DIN 580 |
| Capacity range | 0.4T to 32T safe working load |
| Size range | M6 to M48 |
| Wll M6 | 0.4T |
| Wll M8 | 1T |
| Wll M10 | 1T |
| Wll M12 | 2T |
| Wll M16 | 4T |
| Wll M20 | 6T |
| Wll M24 | 8T |
| Wll M30 | 12T |
| Wll M36 | 16T |
| Wll M42 | 24T |
| Wll M48 | 32T |
Specification values are taken from the supplier's published product data. Sizes and capacities outside the listed range are quoted on request.
Key features
- Grade 80 alloy steel provides high tensile strength for heavy lifting applications
- Minimum breaking load is four times the safe working load (4:1 design factor)
- Red painted finish resists corrosion and improves visibility of markings
- DIN 580 size standard ensures compatibility with common industrial fittings
Typical applications
- Rigging fabricators building custom chain slings and lifting sets
- Lifting service companies replacing worn master links across a fleet of chain slings
- Marine and offshore contractors needing galvanised Grade 80 links for deck and mooring applications
