Zinc Alloy Pulleys
Die Cast Fixed Double Pulley Metal Wheel
Die Cast Fixed Double Pulley Metal Wheel is supplied by Kailipu as part of the Zinc Alloy Pulleys family from Qingdao, and is quoted against the size, capacity and finish your requirement calls for.
6 lines of die cast zinc alloy pulleys with steel or galvanized eyes, single and double wheel, nickel or zinc plated finishes, for cable and rope guid
Specifications
| Finish | Nickel plated, zinc plated, plain, or custom |
|---|---|
| Size 1/2" Dimensions | D 1/2" L 1 5/8" L1 11/32" W 5/16" W1 9/32" E 3/16" Gm/Pc 24 |
| Size 3/4" Dimensions | D 3/4" L 1 5/8" L1 1/4" W 5/16" W1 3/16" E 3/16" Gm/Pc 36 |
| Size 1" Dimensions | D 1" L 2 1/8" L1 3/8" W 13/32" W1 3/8" E 1/4" Gm/Pc 69 |
| Size 1 1/4" Dimensions | D 1 1/4" L 3" L1 1/2" W 17/32" W1 1/2" E 3/8" Gm/Pc 115 |
| Size 1 1/2" Dimensions | D 1 1/2" L 3" L1 13/32" W 17/32" W1 1/2" E 3/8" Gm/Pc 140 |
| Size 2" Dimensions | D 2" L 3 7/8" L1 9/16" W 9/16" W1 1/2" E 1/2" Gm/Pc 282 |
Specification values are taken from the supplier's published product data. Sizes and capacities outside the listed range are quoted on request.
Key features
- Fixed eye design provides stable mounting and reduces swing during operation
- Die cast zinc alloy body offers lightweight strength and resistance to deformation
- Two steel or galvanized metal wheels distribute load evenly across the pulley
- Polished wheel grooves reduce friction and wear on soft rope and cord
Typical applications
- Industrial equipment builders integrating pulleys into control systems or tensioning mechanisms
- Rigging and lifting service companies needing light-duty pulleys for cable adjustment or alignment
- Marine and offshore maintenance teams using pulleys for guide lines on deck equipment
Need this line on an order?
Send the size, the capacity or the whole bill of materials. You will get a quotation and a lead time rather than a catalogue PDF.
